Privilege Escalation via Named Pipe Impersonation

  1[metadata]
  2creation_date = "2020/11/23"
  3integration = ["endpoint", "windows", "system", "m365_defender", "sentinel_one_cloud_funnel", "crowdstrike"]
  4maturity = "production"
  5updated_date = "2026/09/18"
  6
  7[rule]
  8author = ["Elastic"]
  9description = """
 10Identifies a privilege escalation attempt via named pipe impersonation. An adversary may abuse this technique by
 11utilizing a framework such as Metasploit's meterpreter getsystem command.
 12"""
 13from = "now-9m"
 14index = [
 15    "endgame-*",
 16    "logs-crowdstrike.fdr*",
 17    "logs-endpoint.events.process-*",
 18    "logs-m365_defender.event-*",
 19    "logs-sentinel_one_cloud_funnel.*",
 20    "logs-system.security*",
 21    "logs-windows.forwarded*",
 22    "logs-windows.sysmon_operational-*",
 23    "winlogbeat-*",
 24]
 25language = "eql"
 26license = "Elastic License v2"
 27name = "Privilege Escalation via Named Pipe Impersonation"
 28references = [
 29    "https://www.ired.team/offensive-security/privilege-escalation/windows-namedpipes-privilege-escalation",
 30    "https://www.cobaltstrike.com/blog/what-happens-when-i-type-getsystem/",
 31    "https://redcanary.com/blog/getsystem-offsec/",
 32]
 33risk_score = 73
 34rule_id = "3ecbdc9e-e4f2-43fa-8cca-63802125e582"
 35severity = "high"
 36tags = [
 37    "Domain: Endpoint",
 38    "OS: Windows",
 39    "Use Case: Threat Detection",
 40    "Tactic: Privilege Escalation",
 41    "Resources: Investigation Guide",
 42    "Data Source: Elastic Endgame",
 43    "Data Source: Elastic Defend",
 44    "Data Source: Windows Security Event Logs",
 45    "Data Source: Microsoft Defender XDR",
 46    "Data Source: Sysmon",
 47    "Data Source: SentinelOne",
 48    "Data Source: Crowdstrike",
 49    "Noise: Low",
 50    "Performance: Normal",
 51    "Rule Type: Event Correlation (EQL)",
 52    "Platform: Windows",
 53]
 54timestamp_override = "event.ingested"
 55type = "eql"
 56
 57query = '''
 58process where host.os.type == "windows" and event.type == "start" and
 59 (process.name : ("Cmd.Exe", "PowerShell.EXE") or ?process.pe.original_file_name in ("Cmd.Exe", "PowerShell.EXE")) and
 60 process.args : "echo" and process.args : ">" and process.args : "\\\\.\\pipe\\*"
 61'''
 62
 63note = """## Triage and analysis
 64
 65### Investigating Privilege Escalation via Named Pipe Impersonation
 66
 67#### Possible investigation steps
 68
 69- Did the alert process act as a named-pipe client for a SYSTEM-token handoff?
 70  - Why: GetSystem-style abuse pairs a service-context client with a named-pipe server so the server can impersonate the client token; the shell pipe-write is the client-side marker.
 71  - Focus: `process.name`, `process.pe.original_file_name`, `process.command_line`, `host.id`, and `user.id`.
 72  - Implication: escalate when cmd or PowerShell sends a short marker into a named pipe before token impersonation; lower suspicion only when the same pipe name, marker, host, and user match a stable validation pattern.
 73- Does the parent and token context fit a service-driven impersonation attempt?
 74  - Focus: `process.parent.name`, `process.parent.command_line`, broader process lineage when needed, `process.Ext.token.integrity_level_name`, and `process.Ext.token.elevation_level`. $investigate_0
 75  - Implication: escalate when services.exe, service-creation command lines, or an unexplained launcher starts the pipe write under high or SYSTEM context; absent or ambiguous token context cannot close the alert without matching identity and follow-on evidence.
 76- Is the launching binary the expected Windows shell or a masqueraded copy?
 77  - Focus: `process.executable`, `process.hash.sha256`, `process.pe.original_file_name`, `process.code_signature.subject_name`, and `process.code_signature.trusted`.
 78  - Implication: escalate when the shell runs from a user-writable or deceptive path, has an untrusted signer, or mismatches its original file name; signed System32 cmd or PowerShell confirms identity only and does not clear the pipe-write behavior.
 79- Did the pipe writer launch or enable follow-on SYSTEM activity?
 80  - Focus: child process events from `process.entity_id`; review `process.name`, `process.command_line`, and `process.Ext.token.integrity_level_name`. $investigate_1
 81  - Implication: escalate when a shell, tool, service helper, or credential-access process follows under high or SYSTEM integrity; absence of child process evidence lowers only follow-on confidence when pipe syntax or service parentage remains suspicious.
 82  - Hint: if `process.entity_id` is unavailable, use `host.id` plus `process.pid` in a tight alert-time window and treat matches as weaker.
 83- Is this isolated, or part of repeated named-pipe impersonation behavior?
 84  - Focus: process starts sharing `host.id` or `user.id`, marker behavior in `process.command_line`, and either `process.parent.name` or `process.hash.sha256`.
 85    - $investigate_2
 86    - $investigate_3
 87  - Implication: escalate scope when repeats cross hosts, users, hashes, or parent chains; keep response local only when all repeats stay inside the same process-evidenced validation pattern.
 88  - Range: start with the alert window; expand only if local evidence is suspicious or unresolved.
 89- Escalate on suspicious pipe-write syntax, parent/token context, binary identity, follow-on process activity, or host/user scope; close only when all evidence matches a stable validation pattern with no contradictions; preserve artifacts and escalate when evidence is mixed or incomplete.
 90
 91### False positive analysis
 92
 93- Routine administration should not require shell echo redirection into a named pipe for privilege escalation. Controlled security validation is the narrow benign path; process evidence must prove the exact pattern:
 94  - **Identity**: `process.executable`, `process.hash.sha256`, signer, and `process.parent.command_line` match the validation toolchain.
 95  - **Pipe syntax**: `process.command_line` shows the expected pipe name, echo value, and wrapper syntax for that test.
 96  - **Scope**: `host.id` and `user.id` stay inside the known test target and operator scope.
 97  - **Follow-on**: child process starts do not show unexpected high or SYSTEM activity outside the test plan.
 98  - If telemetry cannot prove the test scope or toolchain, outside confirmation can corroborate the case but cannot override contradictory process evidence; otherwise preserve and escalate.
 99- Build exceptions only from the minimum confirmed validation pattern: stable `process.hash.sha256`, `process.executable`, `process.parent.command_line`, constrained `host.id` or `user.id`, and the specific pipe-write shape in `process.command_line`. Avoid exceptions on `process.name`, cmd or PowerShell alone, or a pipe name alone.
100
101### Response and remediation
102
103- If confirmed benign:
104  - Reverse any temporary containment and document the evidence that confirmed the validation workflow: pipe syntax, parent/token context, binary identity, `host.id`, `user.id`, and lack of unexpected follow-on SYSTEM activity.
105- If suspicious but unconfirmed:
106  - Preserve the alert, process tree, command lines, parent and child process records, `process.entity_id`, `process.pid`, hashes, and the named-pipe string before termination, cleanup, or credential actions.
107  - Apply reversible containment tied to the findings, such as isolating the endpoint after weighing host criticality or restricting the affected account/session while investigation continues.
108  - Do not terminate cmd, PowerShell, or child processes until the process identifiers, command lines, and any volatile state needed by responders are captured.
109- If confirmed malicious:
110  - Isolate the endpoint after preservation when parent/token, identity, or follow-on process evidence confirms unauthorized SYSTEM activity.
111  - Suspend or terminate the pipe writer and follow-on processes only after recording their entity IDs, PIDs, command lines, hashes, and parent relationships.
112  - Reset credentials or revoke sessions for affected users only when process/session evidence indicates account misuse or credential exposure.
113  - Eradicate only malicious tools, service definitions, binaries, scripts, and configuration changes confirmed during the investigation, then remediate the entry vector that allowed the named-pipe impersonation attempt.
114- Post-incident hardening:
115  - Restrict local admin and service-creation rights that allow untrusted tooling to create SYSTEM service clients.
116  - Retain command-line, parent/child process, and token-integrity telemetry because those fields distinguish testing from GetSystem abuse.
117  - Document the confirmed benign validation pattern or malicious artifact set so future analysts can separate repeat testing from repeat abuse.
118"""
119
120setup = """## Setup
121
122This rule is designed for data generated by [Elastic Defend](https://www.elastic.co/security/endpoint-security), which provides native endpoint detection and response, along with event enrichments designed to work with our detection rules.
123
124Setup instructions: https://ela.st/install-elastic-defend
125
126### Additional data sources
127
128This rule also supports the following third-party data sources. For setup instructions, refer to the links below:
129
130- [CrowdStrike](https://ela.st/crowdstrike-integration)
131- [Microsoft Defender XDR](https://ela.st/m365-defender)
132- [SentinelOne Cloud Funnel](https://ela.st/sentinel-one-cloud-funnel)
133- [Sysmon Event ID 1 - Process Creation](https://ela.st/sysmon-event-1-setup)
134- [Windows Process Creation Logs](https://ela.st/audit-process-creation)
135"""
136
137[rule.investigation_fields]
138field_names = [
139    "@timestamp",
140    "host.id",
141    "user.id",
142    "process.entity_id",
143    "process.pid",
144    "process.executable",
145    "process.command_line",
146    "process.args",
147    "process.pe.original_file_name",
148    "process.code_signature.subject_name",
149    "process.code_signature.trusted",
150    "process.hash.sha256",
151    "process.Ext.token.integrity_level_name",
152    "process.parent.executable",
153    "process.parent.command_line",
154]
155
156[transform]
157
158[[transform.investigate]]
159label = "Process starts on the host near the pipe write"
160description = ""
161providers = [
162  [
163    { excluded = false, field = "event.category", queryType = "phrase", value = "process", valueType = "string" },
164    { excluded = false, field = "host.id", queryType = "phrase", value = "{{host.id}}", valueType = "string" }
165  ]
166]
167relativeFrom = "now-1h"
168relativeTo = "now"
169
170[[transform.investigate]]
171label = "Child process starts from the pipe writer"
172description = ""
173providers = [
174  [
175    { excluded = false, field = "event.category", queryType = "phrase", value = "process", valueType = "string" },
176    { excluded = false, field = "host.id", queryType = "phrase", value = "{{host.id}}", valueType = "string" },
177    { excluded = false, field = "process.parent.entity_id", queryType = "phrase", value = "{{process.entity_id}}", valueType = "string" }
178  ],
179  [
180    { excluded = false, field = "event.category", queryType = "phrase", value = "process", valueType = "string" },
181    { excluded = false, field = "host.id", queryType = "phrase", value = "{{host.id}}", valueType = "string" },
182    { excluded = false, field = "process.parent.pid", queryType = "phrase", value = "{{process.pid}}", valueType = "string" }
183  ]
184]
185relativeFrom = "now-1h"
186relativeTo = "now"
187
188[[transform.investigate]]
189label = "Alerts associated with the host"
190description = ""
191providers = [
192  [
193    { excluded = false, field = "event.kind", queryType = "phrase", value = "signal", valueType = "string" },
194    { excluded = false, field = "host.id", queryType = "phrase", value = "{{host.id}}", valueType = "string" }
195  ]
196]
197relativeFrom = "now-48h/h"
198relativeTo = "now"
199
200[[transform.investigate]]
201label = "Alerts associated with the user"
202description = ""
203providers = [
204  [
205    { excluded = false, field = "event.kind", queryType = "phrase", value = "signal", valueType = "string" },
206    { excluded = false, field = "user.id", queryType = "phrase", value = "{{user.id}}", valueType = "string" }
207  ]
208]
209relativeFrom = "now-48h/h"
210relativeTo = "now"
211
212[[rule.threat]]
213framework = "MITRE ATT&CK"
214
215[[rule.threat.technique]]
216id = "T1134"
217name = "Access Token Manipulation"
218reference = "https://attack.mitre.org/techniques/T1134/"
219
220[[rule.threat.technique.subtechnique]]
221id = "T1134.001"
222name = "Token Impersonation/Theft"
223reference = "https://attack.mitre.org/techniques/T1134/001/"
224
225[rule.threat.tactic]
226id = "TA0004"
227name = "Privilege Escalation"
228reference = "https://attack.mitre.org/tactics/TA0004/"
